PRO B760M-P

PRO B760M-P

PRO B760M-P is designed with tons of flexible tools with DDR5 memory version.

Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC)
Core Boost : With premium layout and digital power design to support more cores and provide better performance
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength

grazie

SPECIFICHE TECNICHE

Connettore Video	1 x HDMI 1 x DisplayPort 1 x VGA
Alimentazione	24-pin ATX, 1 x 8-pin ATX V
Chipset	Intel B760

CANALI/CONNETTORI

USB 2.0 – interni	4
USB 2.0 – retro	4
USB 3.2 Gen 1 – interni	2
USB 3.2 Gen 1 – retro	1
USB 3.2 Gen 2 – retro	1
SATA revision 3.0 (SATA 6 Gbit/s)	4
PCI-Express 16x	1
PCI-Express 1x	2
Audio	3
Ps/2	2

PROCESSORE

Socket	LGA1700
Famiglia processore	Intel
CPU compatibili	Support Intel® Core 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700

CONTROLLER

Raid	0/1/5/10
LAN	1x Realtek® RTL8111H Gigabit LAN Controller

VIDEO

GPU integrata	Sì
Modello scheda video	Non presente

AUDIO INTEGRATO

Modello scheda audio	Realtek ALC 897
Numero Canali	7.1

MEMORIA

Tipo Moduli	DDR5
Espansione max	192 GB
Frequenza max	6800 MHz
Numero Slot	4
Dual Channel	Sì

GENERALE

Dotazione Hardware	Cavo SATA

DIMENSIONI

Form factor	Micro-ATX
