NVH300 Angler

Descrizione

1D/2D, 1280×960 CMOS, LED, USB, 76 x 107 x 185 mm, 245 gThe NVH300 Angler DP is perfect for scanning DPM barcodes even on reflective, curved or shiny surfaces with its advanced illumination. The intelligent light system switches between illumination types to adjust to the existing light source and simplify the scanning of difficult barcodes. The rugged industrial design and IP64 housing guarantee that the scanner survives even in the harshest environments.

Superior DPM Scanning Packed in a Rugged Design
The NVH300 Angler DP is equipped with direct white light as well as red and blue diffuse illumination to ensure barcodes can be scanned from different materials, shapes, colors and complex backgrounds. NVH300 Angler DP is perfect for industrial, manufacturing and warehousing industries with its rugged design.

New Vision
The NVH300 Angler DP is the first of Newland’s New vision barcode readers designed for high-end and specialist scanning requirements that include an element or combination of; industrial protection, High density and DPM code reading acumen.

DPM Decoding
With a new generation of industrial decoding, the NVH300 Angler DP can read laser marked and dot peened barcodes on many types of surfaces. Surgical equipment, machinal engineering parts and printed circuit boards

Advanced illumination
The NVH300 Angler DP uses three different light sources to combat the contrast variances encountered from different materials marked by the DPM codes. The issues confronted by the reflection and distortion of barcodes can be negated by using different colored light projected from different angles.

Intelligent Configuration
The NVH300 Angler DP uses the three illumination colors it has and the angles of the light source with a level of intelligence by cycling through the options automatically after a short delay in attempting to scan a code. When the ideal light colors and angle combination is found, the NVH300 remembers the last setting for the following code.

Nset
Newlands’s new vision range of scanners is accompanied by its own advanced configuration software. Nset is a more DPM and High-density feature-packed version of our Easyset configuration software.

Industrial Design
The NVH300 Angler DP is fortified inside and out. With an IP64 sealed housing and 1.8m drop specification, the NVH300 DPM is Newland’s most formidable handheld scanner. Dirty, harsh environments are no deterrent to the NVH300 DPM. We back this up with a standard 5 Year warranty.

GENERALE

DECODING

CONNETTIVITÀ

CONDIZIONI AMBIENTALI DI FUNZIONAMENTO

CONTENUTO DELLA CONFEZIONE

DIMENSIONI

Informazioni aggiuntive
